WAFER check valve is a general one-way valve for fluid.Lightweight, small-sized, WAFER check valve iseasy to install between the flange.

The interior of the valve consists of two semi-circular taut springs and plates that fixed to the valve body with a pin. Moving fluid make the spring deform and get through the valve. The valve closes when the spring lose fluid pressure. The spring deforms quickly, which keeps the pipeline from the damage of water hammer.

Keep these in mind when install WAFER check valve

1. First, the priority among priorities, make sure the opening direction is in line with the the flow direction when you put your WAFER check valve in place.

2. Put them in vertical pipelines and, for horizontal pipelines, install check valves vertically.

3. Use a expanding tube between the WAFER check valve and the butterfly valve. Don’t connect them to other valves directly.

4. Keep pipe joints and blockagesaway from the operating radius of the valve plate.

5. Do not install a reducer in front of or perhaps behind the WAFER check valve.

6. When the WAFER check valve have to be installed near a elbow pipe, leave a large enough space.

7. If WAFER check valve is placed at the outlet of pump , allow space at least six times the diameter of the valve to ensure that the butterfly plate can be pushed by fluid.
