Just like there are different advantages between lug or wafer type butterfly valves, 2 piece type and 3 piece type ball valves also have their edges. What below are some of the important factors when considering choices between the two types.

1. Design

2. End connections

3. Installation

4. Performance

5. Ease of maintenance

Design

As their names imply, a 2-piece ball valve has two distinct pieces – one piece is an end connection and the body and a second piece, which has the other end connection as well as the valve trim.

A 3-piece ball valve has three body pieces – 2 ends and a center section that holds the valve trim. The three parts are bolted together around the three sections.

End Connections

Because of their designs, two-piece ball valves are limited in the type of end connections they can make. They are usually limited to threaded end connections.

Three-piece ball valves have a swing design that allows for welded end connections, so socket and butt weld ends are often feasible.

Installation

Its simple design makes 2-pc ball valve one of the most common types in many industries. Due to this simple design, the 2-pc ball valve is a lightweight solution for manual and automatic fluid or gas control.

If the end connection is threaded, the installation of the 3-pc type is also very straightforward. When it is necessary to weld the end, in order to prevent the valve seat and the sealing ring from being heat damage, the device have to be partially disassembled during the installation.

Performance

The simplistic design of 2-pc valve allows itself, generally, a better Cv value. The seats, seals, applications and other parts in performance are more decisive than the design type.

Ease of Maintenance

The oscillating design of the 3-piece valve allows the body section to remain in place while the valve section swings up and out of the line for cleaning or servicing. This feature makes the 3-pc stand out from the 2-pc, whose design does not allow for any maintenance. Applications where the media is thick or viscous, or where lines must be cleaned between batches, are almost always the domain of the 3-pc valve.

summary

Based on the above information, the consideration of 2-pc or 3-pc must include various factors, including the length of the production line through its medium, flow, weight, and maintenance plan. The good news is that our technical sales staff will be more than happy to discuss these factors so that you can make the right decision.
